The datasheet provides specifications, features, antenna options, mechanical drawing, pin description, PCB layout and contact information for the…
The S2SPI-HA/UA/NA-A-434 module is based on the ultra‑low‑power S2‑LP RF transceiver and operates in the 430‑470 MHz and 860‑940 MHz ISM/SRD bands. It offers multiple antenna configurations (UFL, helical, or no antenna) and includes a 4‑wire SPI interface, programmable RF output power up to +16 dBm, and low‑power consumption modes.
The datasheet details the mechanical drawing, terminal pinout, recommended PCB layout, and full electrical specifications such as operating voltage (1.8‑3.6 V), temperature range (‑40 °C to +85 °C), current consumption for various modes, TX power, RX sensitivity (‑131 dBm) and storage limits. Contact information for further support is also provided.
| Operating Voltage | 1.8 V – 3.6 V |
|---|---|
| Operating Temperature | -40 °C to +85 °C |
| TX Power (max) | 14 dBm |
| Current Consumption TX (14 dBm) | 19 mA |
| Current Consumption Sleep | 0.6 µA |
| Storage Temperature | -40 °C to +105 °C |
It supports the 430‑470 MHz and 860‑940 MHz frequency bands.
The module can be supplied with a UFL antenna, a helical antenna, or with no antenna.
The module operates from –40 °C to +85 °C.
