The Baowei turnstile user manual provides installation, setup, operation, troubleshooting and maintenance instructions for the intelligent access control gate.
This manual introduces the Baowei turnstile, an intelligent access‑control device that integrates mechanical, electronic and micro‑processor control with various card‑reading technologies. It describes the device’s structure, electrical interfaces, and safety features for use in hotels, factories, residential areas and other facilities.
The document covers physical dimensions, mechanical and electronic system details, installation steps, commissioning procedures, system parameter settings, common fault handling, routine maintenance, and safe operating guidelines. This manual is written in Chinese.
| Power supply voltage | AC220 ± 10% V, 50 Hz |
|---|---|
| Drive motor | DC motor 24 V / 100 W |
| Operating temperature | -15 °C to 60 °C |
| Relative humidity | ≤ 90 % non‑condensing |
| Input interface | 12 V signal or pulse width >100 ms, drive current >10 mA |
| Communication interface | RS‑485 |
| Communication distance | ≤ 1200 m |
| Gate width | 600 mm |
| Pole length | 600‑900 mm |
| Passage speed | 30 persons/min (open mode), 20 persons/min (closed mode) |
| Gate open/close time | 2‑3 seconds |
The alarm sounds when the system detects an illegal entry into the passage.
The buried PVC conduit should be deeper than 60 mm, and the outlet should be higher than 50 mm above ground.
Use parameter P01: set to 000 for forward rotation or 001 for reverse rotation.
