This datasheet provides pin configuration, electrical characteristics and application information for the LT4761 integrated circuit.
The LT4761 is presented in a DIP8 or SOP8 package and is intended for automotive power‑management applications. The document lists the recommended external components, such as a 100 Ω sense resistor and a 3.3 µF/50 V capacitor, and shows typical voltage ranges for the supply pins.
Typical application circuits illustrate how to connect the device to a 12 V or 24 V battery, with Vbatt values ranging from 9.5 V to 18 V. Electrical specifications include output current limits, sense resistor tolerances and pin voltage limits.
| Supply voltage (Vbatt) | 9.5 V – 18 V |
|---|---|
| Output sense resistor (Rs*) | 0.015 Ω – 0.020 Ω |
| External capacitor (C1) | 3.3 µF / 50 V |
| Pin 2 voltage (Vpin2) | 13.5 V |
The device operates with a battery voltage between 9.5 V and 18 V.
A 3.3 µF capacitor rated for 50 V is recommended (C1).
