The guide explains how ArjoHuntleigh Skin IQ coverlets manage moisture and temperature to prevent pressure ulcers.
The Skin IQ family of powered mattress covers uses Negative Airflow Technology to continuously draw moisture away from the skin surface and control temperature. The coverlets are compatible with most pressure‑redistribution mattresses and are offered in disposable, reusable and bariatric versions.
Technical specifications for the three models (MCM, 365, 1000) include voltage, current, temperature ranges, maximum safe working load and moisture‑vapor‑transfer rates, while clinical data highlight reductions in moisture, temperature, shear, odor and overall cost of care.
| Operating voltage | 100‑240 VAC |
|---|---|
| Operating frequency | 50/60 Hz |
| Ampere rating (MCM & 1000) | 0.5 A |
| Ampere rating (365) | 0.3 A |
| Power cord length (MCM & 1000) | 6 m (19.69 ft) |
| Power cord length (365) | 6.1 m (20.0 ft) |
| Temperature range (MCM & 1000) | 14 °C to 35 °C |
| Temperature range (365) | 0 °C to 40 °C |
| Maximum safe working load | 227 kg (500 lb) |
| Maximum electrical leakage | 100 µA at 115 VAC 60 Hz |
The coverlet operates on an input voltage of 100 to 240 VAC.
The MCM model can safely support up to 227 kg (500 lb).
It can be used from 14 °C (57.2 °F) up to 35 °C (95 °F).
