Technical description of the Apsim product covering signal integrity, power integrity and high‑speed design guidelines.
The Apsim document provides an overview of the product’s technical specifications, focusing on signal integrity, power integrity, and high‑speed circuit design. It includes tables of frequency limits, timing parameters, and example component performance.
The manual also lists a wide range of customers and partners that use Apsim, and provides references to related training resources and company information. This manual is written in Chinese.
| Maximum Frequency (Fmax) | 10 × F2 |
|---|---|
| 74HC Timing | 13‑15 ns, 24 MHz |
| 74LS Timing | 9.5 ns, 34 MHz |
| 74HCT Timing | 5‑15 ns, 64 MHz |
| ECL12K Timing | 1.5 ns, 212 MHz |
The document states that the maximum frequency (Fmax) equals ten times the base frequency F2.
