Allegro MicroSystems A6213 Automotive Grade LED Driver Datasheet

Datasheet for the Allegro MicroSystems A6213, a 3-A constant-current buck regulator for automotive LED applications with PWM dimming.

Brand: Allegro MicroSystems
Category: Other Electronics
Document type: Datasheet
Language: English
Pages: 17
File format: PDF
File size: 636 KB
Published: 13 October, 2026
Updated: 13 October, 2026
MD5 checksum: 9985A7437B0F15761C4D70B27EBDB77E
PDF: Allegro MicroSystems A6213 Automotive Grade LED Driver Datasheet PDF

About this manual

The A6213 is a single IC switching regulator designed to provide constant-current output for driving high-power LEDs in automotive lighting applications. It features a high-side N-channel DMOS switch for DC-to-DC step-down (buck) conversion and integrates a true average current control method using a cycle-by-cycle, controlled on-time technique. The device is available in a compact 8-pin narrow SOIC package with an exposed thermal pad for enhanced heat dissipation.

What's inside

Description
Features and Benefits
Absolute Maximum Ratings
Selection Guide
Pin-out Diagram
Functional Block Diagram
Electrical Characteristics
Characteristic Performance
Functional Description
Equations

Specifications

Supply Voltage	6 to 48 V
Maximum Output Current	3.0 A
Operating Ambient Temperature	-40 to 125 C
Maximum Junction Temperature	150 C
Package Type	8-pin SOICN with exposed thermal pad

Frequently asked questions

What is the maximum output current of the A6213?

The device provides a maximum output current of 3.0 A over the operating temperature range.

How is the LED current level programmed?

The LED current is user-selectable by an external current sense resistor connected to the CS pin.

Download PDF (636 KB)
