The Aideks IT6100B series user manual provides safety instructions, setup, operation, specifications, and remote interface details for the high‑speed…
This manual covers the Aideks IT6100B series high‑speed, high‑precision programmable DC power supplies. It includes safety rules, inspection, installation on a 19‑inch rack, and a quick‑start guide to help users get the instrument running safely and efficiently.
Subsequent sections describe detailed operation such as voltage and current setting, local/remote switching, LIST programming, and the three communication interfaces (RS‑232, USB, GPIB). Technical specifications, troubleshooting FAQs, and service information are also provided. This manual is written in Chinese.
| Output voltage range | 0‑20 V |
|---|---|
| Maximum power | 100 W |
| Voltage regulation | <0.01 % + 1 mV |
| Current regulation | <0.05 % + 1 mA |
| Voltage ripple (20 Hz‑7 MHz) | <1 mV Vrms |
| Voltage resolution | 1 mV |
| Voltage accuracy | ±0.03 % + 3 mV |
Disconnect the power cord, open the fuse cover with a small screwdriver, and replace it with a fuse of the same specification.
The power supply can be switched between 220 VAC ± 10 % (47‑63 Hz) and 110 VAC ± 10 % (47‑63 Hz) using the selector switch on the rear.
Connect a USB‑to‑USB cable; all functions can be programmed through the USB488 interface, which supports standard SCPI commands.
Only authorized personnel may open the unit, it must not be used in life‑support systems, and all warnings in the manual must be followed to avoid injury or damage.
