This manual covers quick start, technical specifications, panel operation and remote control for the ADEX IT6100 series programmable DC power supply.
The ADEX IT6100 series is a single‑output, high‑speed, high‑precision programmable DC power supply. This user manual provides safety information, a quick‑start guide, detailed panel operation instructions, and guidance for remote operation via RS‑232, USB or GPIB interfaces.
Key sections include safety warnings, installation and mounting, technical specifications (voltage, current, ripple, dimensions, etc.), panel functions such as voltage/current setting, milliohm and voltage measurement, and communication setup for PC control. This manual is written in Chinese.
| Output Voltage Range | 0 V – 60 V |
|---|---|
| Output Current Range | 0 A – 60 A |
| Voltage Ripple (20 Hz‑20 MHz) | 4 mV p‑p (up to 30 V), 5 mV p‑p (up to 60 V) |
| Dimensions (W × H × D) | 429 mm × 88.2 mm × 354.6 mm |
| Net Weight | 29 kg |
| AC Input Voltage | 110 V or 220 V, ±10%, 47‑63 Hz |
| Voltage Setting Resolution | 0.1 mV (high‑range), 1 mV (mid‑range) |
