A catalog of ACT Motor 8HS series hybrid stepper motors with technical specifications and wiring diagrams.
The ACT Motor 8HS series hybrid stepper motors are offered in a range of sizes and electrical ratings. The catalog lists step angle, motor length, rated voltage, current, resistance, inductance, torque, lead wire count and weight for each model.
The document also includes wiring connection diagrams, mechanical dimensions, and information on related driver products such as the DM420, DM542 and DM2722 stepper motor drivers.
| Step Angle | 1.8° |
|---|---|
| Motor Length | 28 mm |
| Rated Voltage | 4.6 V |
| Rated Current | 0.2 A |
| Phase Resistance | 23 Ω |
| Phase Inductance | 8.2 mH |
| Holding Torque | 1.4 N·cm |
| Lead Wires | 4 |
| Motor Weight | 50 g |
| Detent Torque | 0.2 N·cm |
| Rotor Torque | 2.5 g·cm² |
The step angle is 1.8 degrees.
The rated voltage is 4.6 V.
Each 8HS motor uses four lead wires.
The holding torque is 1.4 N·cm.
