The ABOV MC96F8208S microcontroller user manual details specifications, features, pin assignments and programming information.
This manual describes the ABOV MC96F8208S 8‑bit CMOS microcontroller, which includes an 8051‑compatible CPU, 8 KB Flash, 256 B SRAM, 256 B XRAM, 18 programmable I/O pins and a 12‑bit ADC with ten channels. It also covers power‑up reset, low‑voltage detection, internal RC oscillator, watchdog timer and various peripheral interfaces such as UART, SPI and I²C.
The document provides detailed register maps, timing diagrams, programming options, power‑saving modes, on‑chip debugging support and guidelines for using the device in embedded applications, along with revision history and packaging options.
| Flash memory | 8 KB |
|---|---|
| SRAM | 256 B |
| XRAM | 256 B |
| CPU core | 8‑bit 8051 compatible |
| Programmable I/O pins | up to 18 |
| ADC resolution | 12‑bit, 10 input channels |
| Operating voltage | 1.8 V to 5.5 V |
| Operating temperature | -40 °C to +85 °C |
| Internal RC oscillator | 16 MHz ±1.5 % |
| Watchdog timer oscillator | 5 kHz |
The MC96F8208S contains 8 KB of flash memory.
It provides up to 18 programmable I/O pins.
The device operates from 1.8 V to 5.5 V.
Yes, it includes a 12‑bit ADC with ten input channels.
