The Polycom® RMX® 1500 Hardware Guide 7.0 is a guide that provides information about the Polycom RMX 1500 hardware device, including its features and characteristics.
This hardware guide describes the Polycom RMX 1500 video‑conferencing system, its modular architecture, and key features such as Linux‑based operation, ATCA chassis, and support for H.323, SIP, ISDN, PSTN and LAN interfaces. It also outlines safety, site, and rack‑installation requirements.
The document includes detailed hardware specifications, system and resource capacity tables, wiring and power‑connection procedures, and step‑by‑step instructions for installing and replacing components like the RTM ISDN 1500 card. This manual is written in Chinese.
| Height | 1U (4.44 cm) |
|---|---|
| Width | 19 in (48.26 cm) |
| Depth | 23.6 in (60 cm) |
| Maximum Weight | 12 kg |
| Audio Media Protocols | G.711, G.719, G.722, G.722.1, G.729A, G.723.1, Siren14, Siren22 |
| Video Media Protocols | H.261, H.263, H.264 |
| Power Input Voltage Range | 100‑240 V AC ±10%, 47‑63 Hz |
| Maximum Power Consumption | 350 W |
| Operating Temperature | 0 °C – 40 °C (22 °F – 104 °F) |
| Storage Temperature | -40 °C – 70 °C (-40 °F – 158 °F) |
| Relative Humidity | 15 % – 90 % non‑condensing |
| Maximum Operating Altitude | 4,500 m (15,000 ft) |
| ESD Tolerance | 4 kV |
The RMX 1500 can consume up to 350 watts of AC power.
The system can support up to 90 video participants in a conference.
The RMX 1500 occupies a 1U height in a standard 19‑inch rack.
It operates between 0 °C and 40 °C (22 °F – 104 °F).
