This Quick Start Guide provides an overview of the basic operations for the Matrix Pro Touchscreen Console, including how to turn on the console, start a new job, change cultural settings, set up the application area, and use the auto-guidance feature.
This guide introduces the TeeJet Matrix Pro 840G/570G agricultural spray control console and explains how to power it on, configure basic settings, and start a spraying task. It provides step‑by‑step instructions for using the touchscreen interface, GPS navigation, and optional auto‑driving features.
Key sections cover power on/off, unit and culture settings, vehicle configuration, execution‑area parameters, navigation modes, marking points, boundary definition, and hardware connections. The guide also references additional manuals for advanced features such as auto‑driving and SCM software updates. This manual is written in Chinese.
| Cable length (power/data) | 3 m |
|---|---|
| Fuse rating (power cable) | 5 A |
| GPS antenna connector | 5‑pin |
| Supported GPS signals | GPS, DGPS, WAAS/RTK, GLONASS |
A valid GPS signal must be present before the console allows you to start a new or continue an existing task.
Press the side tag, select the color mode option, and choose “dark” from the list.
