The TSG128128B series is a widely used and feature-rich 128x128 dot matrix liquid crystal graphic display module based on SMD technology. The module has 22 pins with a pitch of 2.54mm.
The TSG128128B series is a 128 × 128 dot graphic LCD display module based on SMD technology. It features a 22‑pin 2.54 mm pitch connector, T6963C controller LSI, selectable contrast modes, and optional white or green LED backlight. The module operates from 3.3 V to 5 V and works in temperatures from –30 °C to 70 °C.
The datasheet lists mechanical dimensions, electrical parameters, maximum absolute limits, pin functions, MPU interface timing, and a full set of display control commands. It also includes application circuit guidelines and handling precautions for reliable integration into devices.
| Resolution | 128 × 128 dots |
|---|---|
| Dot size | 0.32 mm × 0.32 mm |
| Operating voltage | 3.3 V – 5 V |
| Typical input current | 5.7 mA |
| Operating temperature range | –30 °C to 70 °C |
| Number of pins / pitch | 22 pins, 2.54 mm pitch |
| Backlight options | White LED or Green LED |
The module uses the T6963C controller LSI.
It has 22 pins with a 2.54 mm pitch.
The typical input current is 5.7 mA.
The operating voltage range is from 3.3 V to 5 V (absolute limits –0.3 V to 7 V).
