GA-8ST800 series P4 Titans DDR main-board chinese installation Manual

This manual is a user guide for a product of a certain company, which introduces the specifications and features of the product. It declares the conformity of the product to relevant regulations and directives.

GA-8ST800 series P4 Titans DDR main-board chinese installation Manual - cover page
Brand
GA-8ST800系列
Category
Other
Document type
User Manual
Language
Chinese
Pages
102
File format
PDF
File size
3.8 MB
Published
03 November, 2011
Updated
28 September, 2023
MD5 checksum
38AFD9303C18E8650D1874ADFF08A786
PDF
GA-8ST800 series P4 Titans DDR main-board chinese installation Manual PDF

About this manual

This manual provides step‑by‑step instructions for installing and configuring the GBT GA-8ST800 motherboard. It covers hardware layout, CPU and memory installation, BIOS setup, and peripheral connections.

The document also includes compliance declarations, safety information, and troubleshooting tips to help users achieve a reliable system build with the Pentium 4 processor and DDR memory modules. This manual is written in Chinese.

What's inside

  • Motherboard Layout
  • CPU Installation
  • Memory Installation
  • BIOS Setup
  • IDE and SATA Configuration
  • Peripheral Connections
  • Power Supply and ATX
  • Troubleshooting

Specifications

ChipsetSiS 645DX Host/Memory controller, SiS 962L Multi‑I/O
