XS-1710LDNA is a single board computer designed for users based on Intel® RG82845GV (GMCH) + FW82801DB (ICH4) chipset with Socket 478 package, supporting 400/533 MHz front-end system bus latest Intel® Micro FC-PGA2 CPU, memory support DDR SDRAM (PC133/PC1600/PC2100/PC2700), support multiple IDE interfaces, support 4-port USB 2.0 interfaces, support Gigabit Ethernet, audio functions, TV functions, and support various I/O interfaces.
The EVOC XS-1710LDNA is an industrial‑grade single‑board computer based on an Intel® Pentium 4 processor, supporting DDR200/266/333 memory up to 2 GB, CRT/LAN/Audio/TV output, USB 2.0, and a programmable watchdog. The manual introduces the hardware architecture, key components, and performance specifications.
Installation instructions cover safety precautions, component handling, board mounting, memory and storage installation, and jumper settings. The BIOS chapter explains configuration options, watchdog programming, I/O address mapping, and interrupt assignments, helping users set up and maintain the system safely and efficiently. This manual is written in Chinese.
| Dimensions | 265 mm × 305 mm |
|---|---|
| Operating Temperature | 0 °C to 60 °C |
| Supported CPU | Intel® Micro FC‑PGA2 Pentium 4 and Celeron D processors |
| Maximum Memory | 2 GB DDR (DDR200/266/333) |
| IDE Interface Speed | Ultra ATA/100 (up to 100 MB/s) |
| USB Ports | 4 × USB 2.0 (via two controllers) |
| LAN Controller | Intel 82562ET 10/100 Mbps Ethernet |
| Audio Codec | Standard AC’97 audio chip |
The board provides four USB 2.0 ports through two integrated USB controllers.
It can accommodate up to 2 GB of DDR memory (DDR200, DDR266, or DDR333).
