DSO8060 Handheld Oscilloscope is a portable, high-performance digital oscilloscope with dual channels, 60MHz bandwidth, 250MSa/s sampling rate, and 32K points of memory.
This manual provides safety guidelines, setup instructions, and detailed operating procedures for the Hantek DSO8060 handheld oscilloscope. It includes sections on general safety, front‑panel functions, probe compensation, automatic signal display, and various measurement features.
Additional chapters cover application examples, a built‑in multimeter and signal generator, troubleshooting, technical specifications, and appendices with accessories, warranty information, and maintenance tips. This manual is written in Chinese.
| Channels | Dual channel |
|---|---|
| Bandwidth | 60 MHz |
| Maximum real‑time sampling rate | 250 MSa/s |
| Memory depth | 32 K points (single channel), 16 K points per channel (dual) |
| Display | 320 × 240 pixel color TFT |
| Dimensions | 245 mm × 163 mm × 52 mm |
| Weight | 1.2 kg |
The DSO8060 provides dual channels.
The bandwidth is 60 MHz.
After a full charge the battery can power the device for about six hours.
