This is a user manual for Samsung fully automatic washing machine, which introduces the features, functions and usage of the washing machine.
This manual covers everything needed to set up and use the Samsung XQB70‑Q85S and XQB60‑Q85S front‑load washing machines, including choosing an installation location, leveling the unit, connecting water and drain hoses, and installing the noise‑reduction panel. Detailed instructions guide you through the control panel functions, program selection, detergent loading, and the first wash cycle.
Additional sections describe routine maintenance such as cleaning the exterior, filter, inlet valve filter, and detergent dispenser, as well as a comprehensive troubleshooting guide for common issues like no‑run, no‑drain, no‑fill, and spin problems. Technical specifications and product standards are listed at the end of the document. This manual is written in Chinese.
| Product type | Wave‑type fully automatic washing machine |
|---|---|
| Model | XQB70-Q85S / XQB60-Q85S |
| Dimensions (W×D×H) | 540 mm × 565 mm × 890 mm |
| Standard water consumption (standard program) | 168 L (XQB70‑Q85S) / 144 L (XQB60‑Q85S) |
| Weight | 31 kg |
| Capacity | 7.0 kg (XQB70‑Q85S) / 6.0 kg (XQB60‑Q85S) |
| Rated voltage / frequency | 220 V / 50 Hz |
| Rated power consumption | 330 W |
| Spin speed | 760 r/min |
| Wash noise level (A‑weighted) | 48 dB |
Turn on the power, add a small amount of detergent to the detergent dispenser, open the water tap, and press the start/pause button to run a complete wash cycle without clothes.
Check that the drain hose is positioned correctly, not frozen, and not blocked. If it remains undrained for more than 15 minutes, the buzzer will sound and the display will show “5E”.
Pull the filter down, remove any lint, rinse it with water, and reinstall it securely in the machine.
