This document introduces three isolated analog signal conditioning product series from Dataforth, including temperature sensor input modules, potentiometer input modules, thermocouple input modules, and strain gauge input modules. Each model lists the input range and output range.
The SCMS5B series from Dataforth provides isolated analog signal conditioning with a variety of voltage, current and temperature ranges. This service manual includes installation instructions, wiring diagrams, and detailed specifications for each module variant.
The document lists model numbers, their electrical characteristics, and mechanical mounting options, as well as an appendix of part numbers and connector types for field service and repair. This manual is written in Chinese.
| Output voltage range | 0 V to +5 V |
|---|---|
| Temperature range | −100 °C to +200 °C |
| Current range | 4 mA to 20 mA |
The modules provide an output voltage range of 0 V to +5 V.
The operating temperature range is –100 °C to +200 °C.
The modules can source or sink currents from 4 mA to 20 mA.
