Zhiyuan Electronics ZNE-100 Product Data Manual

ZNE-100 is an industrial-grade embedded network module developed by Guangzhou Zhiyuan Electronics Co., Ltd. It integrates TCP/IP protocol stack internally, allowing users to easily implement network functions for embedded devices, enhancing competitiveness.

Zhiyuan Electronics ZNE-100 Product Data Manual - cover page
Brand
ZNE-100
Category
Other device
Document type
User Manual
Language
Chinese
Pages
42
File format
PDF
File size
2.6 MB
Published
02 October, 2011
Updated
28 September, 2023
Model
ZNE-100
MD5 checksum
02EDE095C6DBE5386C46E9D8F78D370E
PDF
Zhiyuan Electronics ZNE-100 Product Data Manual PDF

About this manual

The ZNE-100 is an industrial‑grade Ethernet‑to‑Serial conversion module that integrates a TCP/IP stack, allowing embedded devices to gain network capability without deep networking knowledge. It supports both TCP Server and UDP Server modes and can be configured via a Windows utility or a web browser.

The manual describes the hardware layout, pin assignments, electrical parameters, and mechanical dimensions, and includes step‑by‑step software configuration procedures, web‑based settings, and a repair program for field service. This manual is written in Chinese.

What's inside

  • Function Overview
  • Hardware Circuit Description
  • Electrical Parameters
  • Hardware Connection and Usage
  • Software Configuration
  • Web Configuration
  • Mechanical Dimensions
  • Repair Procedure

Specifications

Ethernet Interface Speed10 Mbit/s
Maximum Serial Baud Rate115200 bps
CPU32‑bit ARM7
RAM16 KB
Flash Memory128 KB
Electrical Isolation1.5 kV
Input Voltage5 V DC
Maximum Operating Current90 mA

Frequently asked questions

How can the ZNE-100 be configured?

It can be configured with the ZnetCom Utility on Windows or through a web browser interface.

What is the maximum serial baud rate supported by the module?

The serial port supports up to 115200 bps.

What power supply does the module require?

The module operates from a 5 V DC supply and draws up to 90 mA of current.
