Thomson linear motion system covers ball screw drive, ball guide unit, ball screw drive, slide guide unit, belt drive, ball guide unit, belt drive, roller guide unit, linear lift system, linear plunger unit and other products, which can meet various application needs.
The document introduces Thomson's straight line motion system family, covering seven product categories such as ball‑screw drives, belt drives, linear lift systems and various guide technologies. It highlights key performance parameters like thrust, speed, acceleration, precision and load capacity for each type.
Technical tables list dimensions, maximum travel, speed, acceleration, repeat positioning accuracy and load limits. The guide also describes accessories, installation kits, and the advantages of Thomson's patented sealing and lubrication solutions for harsh environments. This manual is written in Chinese.
| Maximum thrust (ball‑screw drive) | 12000 N |
|---|---|
| Maximum speed (ball‑screw drive) | 2.5 m/s |
| Maximum speed (belt drive) | 5 m/s |
| Maximum repeat positioning accuracy | 0.01 mm |
The ball‑screw driven unit can deliver up to 12000 N of thrust.
The belt‑driven unit can reach speeds up to 5 m/s.
