This manual includes specific vehicle maintenance information. Please refer to the “Basic Maintenance Manual” for general maintenance information.
This Service Manual is intended for qualified technicians who service the Honda XR190L motorcycle. It includes safety guidelines, model identification, and comprehensive instructions for fuel, engine, chassis, and electrical systems.
The manual contains specifications, torque tables, special tool lists, wiring diagrams, and maintenance schedules, helping ensure accurate repairs and safe operation of the XR190L.
| Overall length | 2,103 mm |
|---|---|
| Overall width | 842 mm |
| Wheelbase | 1,369 mm |
| Seat height | 827 mm |
| Fuel tank capacity | 12.0 liter |
| Engine displacement | 184.43 cm³ |
| Compression ratio | 9.5 : 1 |
| Curb weight | 137 kg |
| Maximum weight capacity | 95 kg |
Read all of the instructions before you begin and wear appropriate safety glasses, gloves, and protective clothing.
The front axle bolt must be tightened to a torque of 12 N·m.
Model identification is listed on page 5 with the entry "Model name: XR190CT-H".
