This manual contains instructions on how to use TX4302, including precautions before use, installation steps, and firmware upgrade methods
The Promise Technology SATA300 TX4302 is a low-profile PCI controller card designed to support up to four Serial ATA hard disk drives. It features four independent data channels, supporting a maximum data transfer rate of 300 MB/sec and backward compatibility with 33MHz PCI slots. The card does not include RAID capabilities and is intended for use with Windows Server 2003 and Windows XP operating systems.
| Data Channels | four independent data channels (ports), two internal and two external |
|---|---|
| Max Drives | four Serial ATA hard disk drives |
| PCI Slot Speed | 66MHz (recommended) or 33MHz |
| Operating Temp | 32° to 122°F (0°C to 50°C) |
| Max Transfer Rate | 300 MB/sec |
No, the SATA300 TX4302 is only a controller card and is not capable of creating a Redundant Array of Independent Disks (RAID).
The controller supports Windows Server 2003, XP Home, and Professional.
The card supports a maximum of four Serial ATA hard disk drives.
