The FUJIFILM 1 Shot Phantom Quality Control Manual provides an effective Quality Control (QC) program for monitoring the performance of all FUJIFILM CR and DR general radiographic digital image acquisition systems. The 1 Shot Phantom provides a system wide quality analysis by incorporating all Monthly QC tests in a single exposure. In addition to a practical analysis of the digital detector, the test tool provides an image that can be used system wide to help evaluate monitor workstation and laser printer performance. It is acceptable to evaluate the phantom image on the QC workstation however if your facility uses hardcopy printed images to make the final diagnosis, the image must also be evaluated using a printed image. We also recommend that you should follow the manufacturer’s instructions for quality control on all printers and monitors used for final diagnosis.
The FUJIFILM 1 Shot Phantom is a test tool designed to provide a system-wide quality analysis for all FUJIFILM CR (Computed Radiography) and DR (Digital Radiography) general radiographic digital image acquisition systems. It incorporates all monthly QC tests into a single exposure, allowing users to evaluate the performance of the digital detector, monitor workstation, and laser printer simultaneously.
The document outlines specific procedures for setting up phantom exposures for both cassette-based CR and fixed DR systems. It details seven distinct tests divided into monthly and semi-annual schedules, including Relative Sensitivity Calibration, Contrast Evaluation, Sharpness and Jitter, Image Uniformity/Noise/Artifact, Accuracy of Measurement Tools, System Linearity, and Residual Image checks.
| Compatible Systems | FUJIFILM CR and DR General Radiographic Digital Imaging Systems |
|---|---|
| Exposure Settings (Baseline) | 80 kVp, 0.10 second |
| Collimation Size | 1 inch outside the frame (Cassette) or 14x17" (Fixed) |
It is intended for use with FUJIFILM CR and DR General Radiographic Digital Imaging Systems, but it is not intended for Mammography Imaging Systems.
All FUJIFILM General Radiographic Digital Imaging Systems are calibrated to an S# of 200.
