The manual begins with important safety warnings, emphasizing proper grounding, correct power supply, and the need for adequate make‑up air. It also details the power requirements, noting the unit draws 10.8 amps and operates on a 115 V/60 Hz grounded receptacle.
A complete parts list and package contents are provided, followed by detailed assembly instructions for installing the window panel, exhaust hose, and power cord. The guide includes preparation steps, placement recommendations, and instructions for testing the built‑in power‑cord safety device. This manual is written in Japanese.
| Current draw | 10.8 amps |
|---|---|
| Voltage | 115 V/60 Hz |
| Required outlet | 15 A grounded receptacle |
It can be used in any properly wired general‑purpose 15 A household grounded receptacle.
Press the TEST button on the plug head, hear a click, then press the RESET button; the cord will be energized if it works correctly.
The unit should be placed at least 7.8 inches away from the wall.
No, it is not for use with casement windows.
