The document provides safety and precautionary measures for installing and operating the 7XU3F rotating connector, including keeping pipelines clean, securing the connector after installation, and regular inspections to prevent loosening or leakage. It also advises on proper storage conditions to avoid moisture, corrosion, and damage.
Technical limits are outlined, such as maximum rotational speed, temperature, pressure, and compatible media (steam and water). The guide includes a brief description of the connector's structure and quick‑exchange flange design, helping users select appropriate seals and ensure reliable performance under specified conditions. This manual is written in Chinese.
| Maximum rotational speed | < 250 RPM |
|---|---|
| Maximum temperature | < 355 °C |
| Maximum pressure | < 3.5 MPa |
| Thread type | 6-77169-14UNC 2B |
The connector can operate at speeds below 250 RPM.
The connector is rated for temperatures below 355 °C.
The connector can withstand pressures up to 3.5 MPa.
