The Nanpu integrated temperature transmitter converts signals from thermocouples, RTDs, resistance and voltage sensors into a standardized 4‑20 mA current loop. It supports a two‑wire system and offers configurable measurement ranges, high accuracy, and explosion‑proof certification for use in industrial environments such as power, metallurgy, petrochemical, and food processing.
The device operates from a 12‑30 V DC supply (rated 24 V) and includes features like fault monitoring, electromagnetic compatibility, and optional PC configuration via PROFIBUS‑PA or HART protocols. Various mounting options and waterproof connection boxes are provided for flexible installation.
| Supported thermocouple types | B, S, K, E, J, T |
|---|---|
| Supported RTD types | Pt100, Cu50 |
| Power supply | 12‑30 V DC (rated 24 V) |
| Accuracy (thermocouple) | ±0.5 %F |
| Accuracy (RTD) | ±0.2 %F |
| Maximum load resistance | 600 Ω (24 V supply) |
| Operating temperature range | -40 °C to +85 °C |
The device supports thermocouple types B, S, K, E, J, and T.
The transmitter operates from a 12‑30 V DC supply, with a rated voltage of 24 V DC.
Yes, it is certified for explosion‑proof use and complies with relevant standards such as EN 60654‑1 Class C.
