This manual provides step‑by‑step installation instructions for the lock‑key transmitter, central control door lock and main unit of the WO‑3007 anti‑theft system. It also explains the system’s functions, safety precautions, and how to program and learn codes.
Additional sections cover troubleshooting tips, battery replacement, vibration sensor adjustment, and detailed electrical specifications for the main unit and remote control. This manual is written in Chinese.
| Maximum output current | Turn signal 5A×2, horn 10A, central lock 10A |
|---|---|
| Working voltage | 12V ±2V |
| Static current (main unit) | <15mA (excluding display, sensor) |
| Operating frequency | 300 MHz ~ 350 MHz |
| Code learning capacity | Up to 1,000,000 times |
| Vibration sensor current | <1 mA |
| Display current | 20 mA |
| Remote control working voltage | 12 V |
| Remote battery code | 27A/112V |
Replace the battery if it is used frequently, the remote range shortens, or after more than one year of use.
The main unit operates at 12 V ±2 V.
The system can learn up to one million codes.
