The BPT-1861 is a portable three‑phase power analysis instrument that measures voltage, current, power, power factor, harmonics, and imbalance. It features ARM and DSP processing, USB data transfer, and a multilingual LCD interface for easy operation.
The manual provides detailed instructions on setup, measurement functions, component descriptions, routine maintenance, and troubleshooting, along with technical specifications and safety guidelines. This manual is written in Japanese.
| Maximum Phase Voltage | 1000 V |
|---|---|
| Maximum Phase Current | 6000 A |
| Frequency Range | 40‑70 Hz |
| Active Power | 700 kW |
| Power Factor Accuracy | +0.005 |
Check that the main unit is connected to the power source and that the power supply is properly attached.
Wipe the instrument with a soft, slightly damp cloth and mild detergent; avoid abrasive materials.
The battery should be fully charged before first use and re‑charged after each 6‑hour operation cycle.
