This document describes the features and characteristics of the ViewSonic® VA2616w LCD display, including compliance with TCO'03 Displays standards, good visual ergonomics and image quality, energy-saving mode, electromagnetic radiation and noise emissions. The display also meets environmental requirements with recyclability and restrictions on harmful substances.
This manual provides important safety instructions, quick‑start installation steps, and optional wall‑mount procedures for the ViewSonic VA2616w LCD display. It also explains how to connect power and video cables, register the product, and access the on‑screen menu.
Further sections cover display settings, image adjustment, technical specifications, fault diagnosis, cleaning guidelines, and warranty information, helping users operate and maintain the monitor safely and efficiently. This manual is written in Chinese.
| Screen Size | 25.54" (26 inch) wide |
|---|---|
| Pixel Pitch | 0.2865 mm |
| Maximum Resolution | 1920 x 1200 @ 60 Hz |
| Video Input | RGB analog 0.7/1.0 Vp‑p, 75 Ω |
| Power Voltage | 100‑240 VAC, 50‑60 Hz (auto‑switch) |
| Dimensions (W×H×D) | 595.68 mm × 478.84 mm × 254.64 mm |
| Weight | 16.14 lb (7.32 kg) |
| Operating Temperature | 32 °F to 95 °F (0 °C to 35 °C) |
| Storage Temperature | -4 °F to 140 °F (-20 °C to 60 °C) |
| Compliance | FCC Part 15, CE, ENERGY STAR, TCO'03, RoHS etc. |
The display includes an energy‑saving mode that automatically activates after a certain period of inactivity.
