SEW-EURODRIVE MOVITRAC 07 Frequency Inverter Operating Instructions

About this manual

This document provides operating instructions for the MOVITRAC® 07 frequency inverters manufactured by SEW-EURODRIVE. It details unit design variations across sizes 0S through 4, including terminal assignments and wiring diagrams for various power ratings.

The guide covers installation procedures compliant with UL standards, startup sequences using the integrated operating panel or external modules, and parameter loading via LOGODrive programs. It also includes comprehensive fault information lists, status displays explanations, and technical data regarding CE marking, UL approval, and C-Tick certification.

What's inside

• Important Notes
• Safety Notes
• Unit Design
• Installation
• Startup
• Operation and Service
• Fault Information
• Technical Data

Frequently asked questions

What type of motors are MOVITRAC® 07 frequency inverters designed to operate?

These units are intended for operating AC asynchronous motors that are suitable for use with frequency inverters.

What is the maximum power rating for a MOVITRAC® 07 inverter connected to a 230 V single-phase supply?

The unit complies with limit value class B when used with a 230 V, 1-phase connection.

What is the maximum power rating for a MOVITRAC® 07 inverter connected to a 400/500 V three-phase supply?

The unit complies with limit value class A when used with a 400/500 V, 3-phase connection up to 11 kW.
