SC4004A is a 40 characters*4 lines 5*7 dot matrix with cursor LCD display module, using KS0066 or equivalent controller.
This document provides technical specifications for the Honda EB22200X, a 5x7 dot matrix LCD module with an integrated controller. It includes built-in features such as a KS0066 equivalent controller and LED backlight support.
The datasheet details electrical characteristics including operating voltage ranges from 42V to 48V at various temperatures, supply current consumption between 5.2mA and 10.8mA, and logic level thresholds for input signals.
| Display Type | 5x7 DOTS WITH CURSOR ITEM SYMBOL |
|---|---|
| Built-in Controller | KS0066 OR EQUIVALENT |
| Operating Temperature Min | 0 °C |
| Supply Voltage Max at 25°C | 45 V |
| Module Size (Wx HxT) | 190.0 x 54.0 x 8.8 mm |
| Viewing Area (Wx H) | 149.0 x 29.5 mm |
| Supply Current Max | 10.8 mA |
The module size is 190.0 x 54.0 x 8.8 mm.
The viewing area measures 149.0 x 29.5 mm.
The supply voltage ranges from 45 V to 47 V.
