This is a user manual for a projector. It introduces the basic usage methods and precautions of the projector.
This document is the official Owner's Manual for the BARCO VISION 708 projection system. It covers safety instructions, location of controls on the front, rear, and control panels, and detailed procedures for connecting various signal sources including Composite Video, S-Video, RGB Analog, Component, and computer interfaces via RS232 or switchers.
The guide details how to operate the projector using the Remote Control Unit (RCU), covering input selection, picture controls, and specific adjustment modes. It includes instructions for the Random Access Adjustment mode for optimizing image quality, as well as a Service Mode for technicians to manage settings like convergence, memory blocks, and diagnostics.
The projector operates on an AC power voltage of 230V.
The projector requires a grounding-type power outlet because it has a 3-wire grounding plug.
The equipment complies with international safety standards EN60950, UL 1950 and CSA C22.2 No.950.
