Barco 808s Graphics Projector Owner's Manual

About this manual

This document is the owner's manual for the BarcoGRAPHICS 808s projection system. It covers safety instructions, installation procedures, and connection details for various signal inputs including composite video, S-Video, RGB analog, and component video sources.

The guide details how to control the projector using a local keypad or an RCU (Remote Control Unit), including programming addresses and selecting input sources. It also explains adjustment modes such as Analog Picture Controls, Geometry Adjustments, Convergence Adjustment, and Service mode for advanced settings.

What's inside

• Safety instructions
• Location and Functions of Control
• Connections
• Controlling
• Adjustment Mode
• Service mode

Frequently asked questions

What are the operating voltage options for this projector?

The projector operates on either 230V AC or 120V AC depending on the specific article number.

Who is qualified to perform installation and preliminary adjustments?

Only qualified BARCO personnel or authorized BARCO service dealers should handle these tasks.

What type of power outlet is required for the projector's plug?

The 3-wire grounding plug must fit into a grounding-type power outlet.
