This manual provides operating instructions for the GRAPHICS 1208s
This document is the Owner's Manual for the BARCO 1208s Graphics Projector, produced by BARCO NV in January 1997. It serves as a comprehensive guide for users and qualified service personnel, covering safety instructions, installation procedures, and control panel terminology. The manual details how to connect various signal sources, including composite video, S-Video, and RGB analog inputs, and explains the setup of peripheral equipment like remote control receivers.
The guide provides extensive instructions on operating the projector, including how to use the Local Keypad and the Remote Control Unit (RCU). It covers critical adjustment modes such as Picture Tuning, Geometry Adjustments, and Convergence Adjustments. Additionally, it includes a section on the Service mode for technicians, detailing identification, block copying, and password changes, as well as information on the CRT run-in cycle and warm-up procedures.
| Operating AC power voltage (Art. No. R9000893) | 230V AC |
|---|---|
| Safety Standards Compliance | EN60950, UL 1950, CSA C22.2 No.950 |
Installation and preliminary adjustments should be performed by qualified BARCO personnel or by authorized BARCO service dealers.
The operating AC power voltage for Art. No. R9000893 is 230V AC.
The part number and serial number are located at the back side of the projector.
