This manual is the user manual for BARCO DATA 808S projector, which introduces the use of the projector, safety operation, cleaning and maintenance.
The document is an Owner's Manual for the BARCO BARCODATA 808S video projector. It covers safety instructions, installation requirements, and connection procedures for various input sources including composite video, S-Video, RGB analog, and component video.
The manual details how to control the projector using a Local Keypad or an RCU (Remote Control Unit), including setting up project addresses and chaining multiple units. It also explains adjustment modes for picture tuning, color balance, geometry corrections, and service mode functions such as convergence adjustments.
The unit requires a grounding-type power outlet because it uses a 3-wire plug with a third pin.
The equipment contains no user-serviceable parts, and opening the cover exposes users to a risk of electric shock.
