The ASM12712C/17012C is a very low cost voice synthesizer with a 4-bit microprocessor. It has various features including a 4-bit ALU, ROM, RAM, I/O ports, timers, clock generator, watchdog timer (WDT), voice synthesizer, etc. It consists of 22 instructions in the device. With CMOS technology and halt function, it can minimize power dissipation. Its architecture is similar to RISC, with two stages of instruction pipeline. It allows all instructions to be executed in a single cycle, except for program branches and data table read instructions (which need two instruction cycles).
The document describes the ASM12712C/17012C, a very low cost voice synthesizer featuring an internal 4-bit microprocessor. The device includes various components such as ROM, RAM, I/O ports, timers, and a watchdog timer, utilizing CMOS technology to minimize power dissipation.
| Operating Voltage | 2.4V to 3.0V |
|---|---|
| Internal Program ROM Size | 4K x 10-bit |
| Data RAM Capacity | 96x4-bit |
| Instruction Count | 22 instructions |
| Power Supply Current (Typical) | 3 mA |
The oscillator frequency can reach a maximum of 4MHz in RM mode.
The device consists of 22 instructions.
