This document provides technical specifications for the elero GS0400 linear actuator. It lists key dimensional parameters such as the maximum built-in stroke length of 272 mm and a body height of 185 mm.
The sheet also details the limit switch configurations, specifying positions for both 'Piston extended' (Pos. ausgefahren) and 'Piston retracted' (Pos. eingefahren) states. This manual is written in German.
| Max built-in stroke length | 272 mm |
|---|---|
| Min adjustment measure | 235 mm |
| Stroke length | 37 mm |
| Body height | 185 mm |
The maximum stroke length is 272 mm.
The minimum adjustment length is 235 mm and the maximum is 272 mm.
The body mass is 185 mm according to the document.
