This document describes a self-priming screw spindle pump, including its operating parameters such as flow rate, temperature, and pressure.
This document is a technical datasheet for the Allweiler SMS210 ER46D6.9-W63-B-OR, a self-priming screw pump in base version. The pump is designed for the transport of oil and operates under specific temperature and pressure conditions.
Key specifications include a nominal pressure of PN16 on the pressure side and PN100 on the suction side, with flange standards conforming to DIN EN 1092-2. The pump features a right-hand rotation and utilizes simple-acting, non-relieved GLRD bearings. Materials for the housing and covers are specified as EN-GJL-250 and EN-GJS-400-15/ZSV respectively. This manual is written in German.
| Product Type | Self-priming screw pump in base version |
|---|---|
| Nominal Pressure (Suction Side) | PN100 |
| Rotation Direction | Right |
| Bearing Type | Simple-acting non-relieved GLRD |
It is a self-suction screw spindle pump designed in base execution.
