This document introduces the MCF 08 series 2/2 channel remote control valve produced by Müller Co-Ax AG in Germany. The valve is suitable for pressure ranges of 0-100 bar and has two operating modes: normally closed and normally open. It operates by pressure relief and spring reset, and is mainly made of brass material with plastic seals. The actuator of the valve is controlled by an external driver.
This document is a datasheet for the COAX MCF 08, a two-way solenoid valve (2/2-Wegeventil) with a pilot function. It covers various configurations including normally closed (NC) and normally open (NO) states, as well as versions with or without a pilot valve.
The datasheet provides technical specifications for both pneumatic and hydraulic drive options. Key parameters include pressure ranges up to 100 bar, nominal sizes of DN 8 mm, and connection types such as G3/4 thread or flange connections. It also lists electrical data for solenoid coils (AC/DC) and mechanical dimensions. This manual is written in German.
Yes, the document specifies 'Typenbezeichnung mit Pilotventil' (Type designation with pilot valve).
The rated pressure range (Druckbereich) extends up to a maximum of 100 bar.
The nominal voltage (Nennspannung) for the pneumatic drive variant is 24 V DC.
