TROVIS 6495-2 Industrial Controller is a digital controller for automating industrial and process plants for general and more complex control tasks
The SAMSON TROVIS 6495-2 is a digital industrial controller designed for panel mounting (96 x 96 mm). It features two independent internal controllers with common input and output sections, allowing for quick adaptation to various control tasks via configuration items and parameters. The device supports multiple control types, including fixed set point, follow-up, ratio, cascade, and override control.
| Mounting type | Panel mounting |
|---|---|
| Internal controllers | Two independent internal controllers |
| Analog inputs | Four |
| Digital inputs | Four |
| Analog outputs | Three |
| Relay outputs | Four |
| Transistor outputs | Three |
| Degree of protection | IP 65 |
| Supply voltage AC | 85 to 264 V AC |
| Supply voltage DC | 24 V AC/DC |
They are controlled by a 24 V DC voltage signal or by the transmitter supply using a floating contact.
Yes, the settings are saved in non-volatile memory even when the power supply fails.
