This document describes the installation steps for the Flo‑Torq Reflex drive hub, including assembling the drive sleeve onto the propeller and using a thrust washer to ensure proper seating.
This document provides step-by-step instructions for installing the Flo-Torg Reflex Drive Hub. The primary task involves assembling the drive sleeve with the aft drive sleeve to ensure there is no gap between them.
Once assembled, the drive sleeve assembly is inserted onto the propeller. An aft washer is then installed and tapped lightly until it contacts the propeller, indicating the assembly is properly seated. The document notes the requirement for a specific thrust washer included with the kit.
The installation requires the use of the thrust washer that is included with the drive hub kit.
