This document provides technical specifications for the Bass KD005265-000 threaded insert. The part is identified by article number 005265 and features a metric thread profile.
Key dimensional data includes an outer diameter of 38 mm, a length of 17.5 mm, and a thread specification of M6 according to DIN 275 / 297. The insert is designed with a right-hand spiral thread. This manual is written in German.
| Outer Diameter | 38 mm |
|---|---|
| Length | 17.5 mm |
| Thread Size | M6 |
