This document is the catalogue of electric magnetic float switch products of Krohne. It mainly introduces the types, materials, connection methods, temperature range and pressure of the products.
This document provides technical data for KSR Magnetic Float Switches, covering materials such as stainless steel and titanium, and various connection options including PVC, silicone, and aluminium. It lists specifications for different process connections and mounting configurations.
| Material | Stainless steel SS 316 Ti (1.4571), 1.4435, 1.4539, Titanium, Hastelloy |
|---|---|
| Connection | Cable PVC grey, PVC blue, Terminal box Aluminium |
| Ingress protection | IP 65 |
| Switch rating closing | 230V AC; 100VA; 1A |
| Switch rating opening | 230V AC; 100VA; 1A |
| Switch rating change-over | 230V AC; 40VA; 1A |
| Orientation | Vertical + 30° |
| Float type V44A guide tube OD | 12 or 14mm |
| Float type V80A guide tube OD | 18mm |
-10°C to +80°C.
-30°C to +150°C.
