CAMLOC 50F Series Technology Data

CAMLOC 50F Series Technology Data - cover page
Brand
CAMLOC
Document type
Product Leaflet
Language
German
Pages
1
File format
PDF
File size
488 KB
Published
10 July, 2012
Updated
19 July, 2012
MD5 checksum
3A44D4E1385A87A92DCF7B94DB6B632B
PDF
CAMLOC 50F Series Technology Data PDF

About this manual

This document provides technical data for the CAMLOC 50F series of fasteners (Verschlusszapfen). It details various configurations including slotted heads and cross-slotted heads made of stainless steel. This manual is written in German.

What's inside

  • Produkt Darstellung
  • Werkstoff
  • Oberflache
  • Schlitzkopf
  • Kreuzschlitz
  • Sechskant
  • Zugbelastung

Specifications

Maximum Tensile Load2.600 N max.
MaterialStahl rostfrei
Surface Treatmentverzinkt

Frequently asked questions

What is the maximum tensile load rating for this product?

The maximum tensile load is 2,600 N.

How do you calculate the value S based on the length number?

You multiply the length number by 0.6 and add it to 11.40.
