Crouzet EB2M/EBA2M/EBP2M Limit-Switch Box Product Data Sheet

This document provides detailed parameters information of the EB2M series limit switches, including protection class, wiring method, voltage, current, power, installation method, etc.

Crouzet EB2M/EBA2M/EBP2M Limit-Switch Box Product Data Sheet - cover page
Brand
Crane
Document type
Product Leaflet
Language
German
Pages
2
File format
PDF
File size
320 KB
Published
10 July, 2012
Updated
30 September, 2023
MD5 checksum
CFFACD87CD93945A2DF5851051D64062
PDF
Crouzet EB2M/EBA2M/EBP2M Limit-Switch Box Product Data Sheet PDF

About this manual

This document provides technical specifications and product information for the Crouzet EB2M, EBA2M, and EBP2M series of limit-switch boxes. These units are designed to house two mechanical switches and feature an enclosure with an IP65 rating according to DIN 40050. This manual is written in German.

What's inside

  • Technical Features
  • Article Numbers and Accessories
  • Connection Diagram
  • Adjustment of Cams
  • Dimensions

Specifications

Protection RatingIP65 according to DIN 40050
Cable Gland SizeM20x1,5
Voltage Rating (AC)250V AC
Current Rating (DC)2,5A (24V DC)
Contact MaterialSilver — Silver — Argento
Operating Temperature Range-20° --- +80°C

Frequently asked questions

What is the protection rating of these limit-switch boxes?

The enclosure has a protection degree of IP65 according to DIN 40050.

What type of switches are included in these boxes?

The boxes include two mechanical switches manufactured by Crouzet, specifically type 83161.3.
