This is a hydraulic cylinder drawing
This document provides technical specifications for the HYDROPNEU SZ.008.08.2.0 pneumatic cylinder. The device is a double-acting cylinder with a piston stroke of 32mm and a bore diameter of 18mm. It features end cushioning without a buffer stop.
The cylinder is designed for a maximum operating pressure of 100 bar and a maximum test pressure of 150 bar. The maximum piston speed is rated at 1000 mm/s. The document includes dimensional views labeled Ansicht X and Ansicht Y. This manual is written in German.
| Test pressure | 150 bar |
|---|---|
| Operating mode | double-acting |
| Piston stroke | 32mm |
| Bore diameter | 18mm |
| Max piston speed | 1000 mm/s |
The test pressure is 150 bar.
Yes, the operating mode is double-acting.
