Italgroup IAM 1600/C-1800/C-2000/C-2200/C H5 technology data

About this manual

This document provides technical information for the Italgroup IAM series of hydraulic motors. It covers specific models including the IAM 1600/C, 1800/C, 2000/C, and 2200/C variants utilizing H5 technology.

The datasheet details physical dimensions such as drain port sizes (3/4" BSP), mounting hole configurations, and shaft options. It also lists compatible connection blocks for specific distributor models.

What's inside

• Hydraulic Motors
• IAM Series Models
• Mounting Holes
• Drain Ports
• Shaft Options
• Connection Blocks

Frequently asked questions

What is the diameter of the mounting holes for this hydraulic motor?

The mounting holes have a diameter of 17.

What is the bolt circle diameter for the mounting holes?

The bolt circle diameter is 380.

What is the size of the drain port on this motor?

The drain port is 1/2" BSP.
