The MiniTest 650 is a rugged and high-precision coating thickness gauge designed for any measuring task in the finishing industry. This durable and easy-to-handle gauge offers extended mechanical life and high accuracy, making it suitable for professional users in industries such as shipbuilding, automotive, bridge building, and construction. Depending on the model, the MiniTest 650 can measure non-magnetic coatings such as paint, enamel, chrome, and zinc on steel, as well as insulating coatings such as paint, anodising, and ceramics on non-ferrous metals like aluminium, copper, zinc die-cast, and brass.
The ElektroPhysik MiniTest 650 is a rugged coating thickness gauge designed for durability and high-precision measurements in the finishing industry. It features a rubber-protected casing and a wear-resistant carbide metal tip sensor. The device is available in three models: one for steel substrates using magnetic induction, one for non-ferrous metals using eddy currents, and a dual-sensor model that automatically switches between principles.
| Minimum curvature radius | 25 mm / 1" concave |
|---|---|
| Minimum base thickness | 50 µm / 2 mils |
| Display | 4-digit screen |
| Power supply | 3 Micro AAA batteries |
| Dimensions (housing) | 70 mm x 122 mm x 32 mm |
| Weight | 225 grams |
The FN model has a dual sensor that automatically switches to the suitable measuring principle based on the substrate material.
The measuring principle conforms to DIN, ISO, BS, and ASTM norms and standards.
