Calpeda SPV series immersion pumps, with power range of 0.08-0.40 kW, head range of 0-360 m, are suitable for the transportation of liquids in cleaning systems, emulsions, coolants, etc., as well as the drainage of collection tanks or pits.
This document is a product leaflet for Calpeda submersible pumps with open impellers, specifically covering the SPV series and the IMM series (IMM 40-100). The pumps are designed for close-coupled installation where the motor and pump body are submerged in the medium being pumped.
The leaflet details the applications, which include the transfer of liquids in cleaning plants, emulsions, coolants, and water disposal from basins or pits. It specifies operating conditions such as a medium temperature range of -20°C to +90°C and a maximum permissible pump discharge pressure of 3 bar. The document also provides technical specifications, including motor details (2-pole induction motor, 50 Hz), materials (Valox pump casing, various impeller materials), and warranty information. This manual is written in German.
| Impeller Type | Open |
|---|---|
| Max. Kinematic Viscosity | 20 mm²/s |
| Max. Medium Temperature | +90 °C |
| Max. Ambient Temperature | 40 °C |
| Max. Discharge Pressure | 3 bar |
| Motor Type | 2-pole induction motor |
| Motor Frequency | 50 Hz |
| Pump Casing Material (SPV) | Valox |
| Pump Casing Material (IMM) | Valox / Aluminium / GG |
| Warranty (Spritzing) | 12 months |
| Warranty (Defector) | 1 year |
They are suitable for liquids in cleaning plants, emulsions, coolants, and water disposal from basins or pits.
The medium temperature can range from -20°C to +90°C.
The maximum permissible pump discharge pressure is 3 bar.
