EMMEGI MGB 131 Series Water-Oil Heat Exchangers Product Catalogue

EMMEGI MGB 131 Series Water-Oil Heat Exchangers Product Catalogue - cover page
Brand
EMMEGI
Category
Other
Document type
Product Leaflet
Language
English
Pages
1
File format
PDF
File size
256 KB
Published
10 July, 2012
Updated
23 July, 2012
MD5 checksum
C5B259014BC32F355DD685F8FF79E5AF
PDF
EMMEGI MGB 131 Series Water-Oil Heat Exchangers Product Catalogue PDF

About this manual

The document describes the EMMEGI MGB 131 series of water-oil heat exchangers. It highlights a key feature: a controllable water circuit with one, two, or four passes. The text includes a legend for the diagrams and a table listing standard materials used for various components such as tubes, sheets, baffles, and seals.

What's inside

  • Water-Oil Heat Exchangers
  • Controllable Water Circuit
  • Standard Materials
  • Technical Characteristics
  • Performance Diagram
  • Pressure Drop
  • Product Catalogue

Specifications

Water Circuit ConfigurationOne-two-four ways controllable
Tube MaterialCuDHP
Sheet MaterialAISI 304
Baffle MaterialAISI 306
Cover MaterialAISI 304

Frequently asked questions

What is the maximum water temperature rating for these heat exchangers?

The unit is rated for a maximum water temperature of 250°C.

How many pass configurations are available for the water circuit?

The water circuit can be configured as one, two, or four passes.
